In the mining and aggregate industry, the efficiency, product shape, and reliability of your crushing equipment directly determine your cost per ton and profitability. As a market promotion expert, we present a complete matrix of key crushing equipment – from feeding to grinding, and from wear parts to OEM critical components.
| Category | Equipment | Key Technical Highlights |
|---|---|---|
| Feeding & Conveying | Grizzly Feeder, Chain Conveyor | Heavy-duty grizzly removes fines to protect crushers; chain conveyor resists impact and abrasion |
| Screening | Double-Layer Screener, Triple-Layer Screener | High-efficiency classification, precise product size control |
| Primary Crushing | Jaw Crusher – including jaw plate, spring | Deep cavity, high throughput; jaw plates in Mn steel/alloy steel; spring provides overload protection |
| Secondary/Tertiary Crushing | Advanced Double Roll Crusher | ✅ Yield up to 70-80% of qualified round-shaped aggregates, extremely low flakiness – ideal for high-grade applications |
| Fine Crushing/Shaping | Cone Crusher | Interparticle crushing, excellent particle shape, high automation |
| Grinding | Raymond Mill – including grinding roller, grinding ring, blade | For limestone, calcite, and non-metallic minerals; blade feeds material between roller and ring for controlled fineness |
Our crushing lines cover 100 tph to 2000 tph for all mining applications. Through modular combinations (jaw crushers, cone crushers, roll crushers), we provide flexible configurations from small to large open-pit mines, ensuring stable operation across the entire capacity range.
Material types: High-chrome cast iron, wear-resistant alloy steel, bi-metal composite, heat-resistant steel (e.g., ZG40Cr25Ni20)
Applicable components: Jaw plates, impact bars, hammers, roll shells, cone crusher mantle/concave, blades, etc.
Lifetime advantage: 30%–100% longer wear life compared to conventional Mn steel – ideal for high-silica, highly abrasive ores
We support individual supply and OEM customization for all key parts:
Jaw plates: Mn13Cr2, Mn18Cr2, imported alloy steel
Springs: Fatigue-resistant cylindrical helical springs – GB/JIS/DIN standards
Grinding roller/ring: High-chrome wear-resistant iron, ceramic composite layer
Blades: Wear-resistant alloy steel – custom angle & thickness
Roll crusher shells: Serrated or smooth type with hardfacing overlay
Cone crusher parts: Bronze bushings, seals, hydraulic cylinders
Reverse engineering, drawing-based production, and small-batch fast delivery available.
Full process coverage – from feeder to mill: one-stop procurement
High-yield technology – advanced double roll crusher yields 70-80% round-shaped aggregates, reducing recirculation load
In-house wear parts – proven heat-resistant alloy formulations for severe conditions
Flexible capacity – 100–2000 t/h, easy to scale
OEM capability – replacement or upgrade of critical parts for any brand of crusher
Contact us today for a customized crushing line solution and wear parts quotation.
